Application
Variants
Functional description
Static differential pressure transducers function according to the static differential pressure measurement principle. The sensor is a cylinder that consists of two chambers (one for positive pressure and one for negative pressure) separated by a diaphragm. If there is equal pressure in both chambers, the diaphragm is in the middle between the chambers and is not deformed. If there is a pressure difference, the diaphragm deforms towards the chamber with the negative pressure. The degree by which the diaphragm deforms is a measure for the differential pressure. This is why the voltage signal is proportional to the differential pressure.
Differential pressure transducer for the LABCONTROL system, for the measurement of room or duct pressure.
When the transducer is connected to a room controller, the supply air or extract air flow is controlled based on the differential pressure.
